Item
Data
Inserts MatchingD10A Hoods&Housings
APPROVAL UL.CSA.VDE.CE.CQC
Test standard DIN EN61 984 / UL1977
Poles 10P+PE
The need for additional or dering crimp contacts Yes, 16A contacts
EN61984 Test data /
Rated voltage [V] 250
Rated current [A] 16
pollution degree 3
Rated impulse voltage [KV] 4
Insulation resistance ≥1010Ω
UL/CSARated current [V] 600
Material Polycarbonate
Inflammability class(UL94) V-0
Ambient temperature [≧] -40~+125
Mechanical working life(mating cycles) ≥500
Contacts
Material Copper alloy
Surface Hard-silver plated
Hard-gold plated
Contact resistance ≤1mΩ
Terminal Crimp terminal
Rated connection capacity)(solid/stranded 0.14—4.0mm² (AWG26-12)
Recommended stripping length7.5mm
